We're professional PTFE fabric backing lining sheet manufacturers and suppliers in China, to buy or wholesale from our factory. For quotation or if you have any questions, contact us now for customized and price.
Imported PTFE resin as the base material, with high-strength glass fiber fabric (warp and weft density ≥200 mesh) as the backing. Through the "resin-fabric" melting process, both corrosion resistance and structural strength are balanced.
RANA, relying on over 30 years of fluoropolymer manufacturing experience, adopts the independently developed hot-press composite process (temperature 280°C, pressure 5MPa) to achieve "bubble-free and delamination-free" fusion of PTFE resin and glass fiber fabric.
The glass fiber fabric serves as a reinforcing framework, endowing the lining Sheet with excellent tear resistance (tear strength ≥80N/mm) and creep resistance (deformation ≤0.5% after 1000 hours at 200°C), while retaining the chemical inertness of PTFE.
Tested by SGS, the peel strength can reach 7N/cm, with a temperature resistance range of -200°C to 260°C, filling the gap in domestic high-performance composite lining technology. As a qualified supplier of Sinopec, the product has passed ISO 9001 certification.
Widely used in large storage tanks (50-150m³), international standard containers, and other equipment requiring large-size linings. It has provided solutions for SMIC and AUECC (USA), solving the problems of easy deformation and tearing of large-size lining Sheets, and increasing equipment service life by 3 times.
RANA possesses mature overseas service capabilities. It has established branches in many parts of the world to build a sales and service network. Through international technical cooperation, it has made its products compatible with the standards of many countries. It can provide customized solutions for the special working conditions of overseas customers. It has formed a multilingual professional team to provide on-site support and rapid spare parts supply. Its products are exported to many countries and have obtained certifications from international giants. It also continues to invest in research and development and innovation to continuously improve service quality and product performance to meet the needs of overseas markets.
Ranatank focuses on providing high-quality fluoropolymer PTFE / PFA / ECTFE / PVDF lined storage tanks, mobile tanks, ISO containers and anti-corrosion equipment and excellent service with 30+ years’ expertise. Ranatank provides you with wholesale, customization, OEM & ODM service...
If you have any questions about PTFE fabric backing lining sheet, please don't hesitate to contact us at any time. We will provide detailed information and technical support about the features, specifications, solutions and customization options of fluoropolymer PTFE / PFA / ECTFE / PVDF lined storage tanks, mobile tanks, ISO containers and anti-corrosion equipment... Welcome you to visit our factory!
